AD9680BCPZ-820
| Manufacturer Part Number | AD9680BCPZ-820 |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Detailed Description | IC ADC 14BIT PIPELINED 64LFCSP |
| Package | 64-LFCSP (9x9) |
| In Stock | 129 pcs |
| Data sheet | AD9680 09/Dec/2016AD9680 Series DatasheetGrasp the Critical Issues for a Functioning JESD20JESD204B Subclasses Part 2 |
Reference Price (In US Dollars)
| 1 |
|---|
| $300.064 |
Delivery Time
Components-House.com is a Reliable Stocking Distributor of Electronic Parts. We specialize in all Analog Devices Inc. series electronic components. We have 129 pieces of Analog Devices Inc. AD9680BCPZ-820 in stock available now. Request a quote from electronics components distributor at Components-House.com, our sales team will contact you within 24 hours.
RFQ Email: info@Components-House.net
RFQ Email: info@Components-House.net
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Voltage - Supply, Digital | 1.8V ~ 3.3V |
| Voltage - Supply, Analog | 1.8V ~ 3.3V |
| Supplier Device Package | 64-LFCSP (9x9) |
| Series | - |
| Sampling Rate (Per Second) | 820M |
| Reference Type | Internal |
| Ratio - S/H:ADC | 1:1 |
| Package / Case | 64-WFQFN Exposed Pad, CSP |
| Package | Tray |
| Operating Temperature | -40°C ~ 85°C |
| Product Attribute | Attribute Value |
|---|---|
| Number of Inputs | 2 |
| Number of Bits | 14 |
| Number of A/D Converters | 2 |
| Mounting Type | Surface Mount |
| Input Type | Differential |
| Features | - |
| Data Interface | SPI |
| Configuration | ADC |
| Base Product Number | AD9680 |
| Architecture | Pipelined |
